We have enough experience to manufacture various kind of disposable product like chopstick, toothpick, spoon, straw, tongue depressor, sticker, acupuncture, cap and etc over 40 years requested by all world customers and expanding to export to Japan, U.S.A, Malaysia, Philippine, Brazil, China, Taiwan and many countries.

*Specification
1. Machine Size : 2,200(L) x 1,560(W) x 1,760(H) (mm)
2. Productivity : 180 ~ 250 pcs/min
3. Packing Material Diameter : Max 650mm (Band type)
Material : Ordinary Paper
4. Chopstick Spec : Length - 165mm or 195mm or 210mm or 240mm
Disposal chopstick
5. Sealing Type : 3-side glue sealing by each 1 toothpick
6. Printing Equipment : 2 color roller style
7. Motor : 0.4kw, 110/200V multiple use
8. Weight : 420kgs
9. Standard accessories : Spare parts , tool 1set and Manual
10. Installation and commissioning is not included.

*Specification
1. Machine Size : 2,400(L) x 1,560(W) x 1,760(H) (mm)
2. Productivity : 180 ~ 250 pcs/min
3. Packing material diameter : Max 650mm(Band type)
                               Material : Ordinary Paper
4. Sealing shape : 3-side glue sealing
5. Printing : 3-color roller type
6. Motor : 0.75kw , 200V(3phase)
7. Drying equipment : 200V, 0.5kw
8. Weight : 450kgs
9. Equipment
  Auto Counter, Vacant bag removing equipment,
  Auto stopping equipment
  Toothpick supplying equipment (* Option),
  Broken & one-side chopstick removing equipment
  Products transporting conveyor
10. Installation and commissioning is not included.

*Specification
1. Machine size : 1,850(L) ?? 650(W) ?? 1,555(H) (mm)
2. Productivity : (1) OPP : 150 ~ 200 pcs/min
                           (2) Paper : 180 ~ 250 pcs/min
3. Roll Film(or paper) Diameter : Max 500??
4. Sealing method : (1) OPP : Heat sealing by heater
                               (2) Paper : By glue
5. Printing : (1) OPP : User have to use printed film(OPP).
                                  Printing on film is not available.
                    (2) Paper : 2 color printing
6. Motor : 0.75kw, Invertor
7. Weight : 450kgs
8. Equipment
  Toothpick supplying equipement (option)
  Vacant paper bag removing equipment
  Metal detecting equipment(option)
  Eye marking sensor - attached

*Specification
1. Machine Size : 2,767(L) x 1,000(W) x 1,407(H) (mm)
2. Productivity : OPP 250 ~ 300 pcs/min
3. Film Roll Max Diameter : 400mm
4. Sealing shape : 4-side sealing
5. Sealing method : Heater
6. Motor : 0.75kw, Invertor motor
7. Weight : 800kgs

*Specification
1. Machine size : 2,650(L) x 800(W) x 1,250(H) (mm)
2. Producing Capacity : 250 ~ 450 pcs/min
3. Printing Equipment : upper - 2 color printing
down - 2 color printing
4. Packing paper spec : 6 inch - 200mm
7 inch - 230mm
5. Packing Material Diameter : Max ??600
6. Sealing shape : P.E sealing by Heater
7. Motor : DC 0.75kw
8. Weight : 1,100Kgs

*Specification
1. Machine size : 8,400(L) x 1,310(W) x 1,940(H)(mm)
2. Product size : (1) Chopstick : 203mm
                           (2) Toothpick : ø2 x 60(mm)
                           (3) Wet towel : 40 x80(mm)
3. Productivity: 40 ~ 60 pcs/min
4. Sealing method : 4-side heat seal
5. Packing method : Individual
6. Power : servo motor : 2Hp x 1pc, 1Hp x1pc
                 heater : 220V, 300W x 8pcs
                             220V, 250W x 16pcs
7. Weight : 2,800kgs
